特点说明：MACHINE CHARACTERISTICS
●本机型针对通讯产业制造领域（同轴线缆加工）而设计，适用于不同规格同轴线和屏蔽线的加工。对碰刀切断减少损耗，两刀头相互配合的设计使得所加工的产品具有高质量和高产量。线材的切断，多层或多段剥皮可一次完成；可加装划皮装置，脱皮长度可根据要求定制；接口可应用不同的外接设备。多年来，本公司一直以客户之上，质量第一的原则，努力提高客户满意度。在通讯、航天行业获得广泛好评。
●This model is designed for the communications industry manufacturing （coaxial cable processing）,used for the processing of different specifications of coaxial and shielding cable. Reduce the loss of the cutting section. The left the two segment to cooperate with each other design makes the processed products have high yield and quality. Wire cutting ,stripping layers can be completed at a time. Can be fitted with a slitting blade device，slitting length can be customized upon request. Interfaces can be applied to different external devices. Over the years, Our Company has been in the customer first，quality first principle，strive to improve customer satisfaction. In the communications, aerospace industry has been praised by many customers.
机械规格：MACHINE SPECIFICATION
型号Modle | HC-9500 |
外形尺寸 Dimensions | 790x720x475(MM) |
重量 Weight | Approx 183.5KG |
最大加工尺寸 Max outer diameter | 9MM |
最小加工尺寸 Min outer diameter | 1.37MM |
最大加工长度 Max cutting length | 99999MM |
最小加工长度 Min cutting length | 60MM |
剥皮能力 Stripping length | 前端最大剥皮长度:60MM,后端最大剥皮长度：45MM,中间留胶皮不短至50MM Front end:max60mm Rear end stripping length:max45mm stay shortest insulation :50mm |
最小剥皮长度 Min stripping length | 0.1MM |
最大剥皮层数 Max stripping steps | 9 |
切割深度单位 Incise depth | 0.01MM |
产量 Production rate | 依作业线总长及作业程序不同，最少可达200PCS/小时 （长度100MM） Approx200pcs/h（length：100mm）depending on conductor and programming |
驱动方式 Drive supply | 伺服电机/滚珠丝杆驱动 伺服电机/滚珠丝杆驱动 motor/roll shot silk stem drive |
旋切刀片 Rotating blades | 2片，材质：进口高速钢 2pieces material：imported Switzerland tungsten steel |
夹线装置 Trapper | 自动调心，电机驱动，夹紧力度程序控制 Automatics self aligning，motor drive，the clamping process control |
存储容量 Database capatity | 100种电缆加工数据 100 different conductors along with all processsing parameters. |
电源功率 Power | AC220V/50/60HZ280W |
工作环境 Working environment | 0—50度，干燥度适中，无振动的工作台面 0—50°C moderate dry，non-shake |
